Amplificator 100V Omnitronic MPZ 500.6

Aplications:

•     Comfortable control of PA speakers via 6-zone technology
•     6 PA zone outputs, independently switchable on the front panel
•     Master PA output (70 V and 100 V)
•     Output for low-impedance speakers (4-16 ohms)
•     2 rear microphone inputs (6.3 mm jack, unbal.)
•     1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
•     All microphone inputs with separate level controls
•     3 line inputs (stereo RCA) with separate level controls
•     1 line output (stereo RCA)
•     Chime, switchable
•     Treble and bass control for the output signal
•     7-fold LED level display
•     Master control for the output signal
•     Fan-cooled
•     Protection circuits with LED indication: over current, short circuit, turn-on delay
•     Rack installation, brackets detachable

Technical specifications:

• Power supply:    230 V AC, 50 Hz ~
• Power consumption:    1000 W
• Output type:    70 V, 100 V or 4-16 ohms
• Output current:    7 A (70 V), 5 A (100 V)
• Mic inputs:    5 mV, 600 ohms
• Line inputs:    300 mV, 10 kohms
• Speaker connectors:    Screw connectors, terminal block
• Frequency range:    80 Hz - 16 kHz
• Distortion:    0.5 % (1 kHz)
• S/N ratio:    85 dB (line), 75 dB (mic)
